Introducing SEQTRAK, the ultimate music creation station that empowers you to capture, create and connect with fans – from anywhere you happen to be.
Unleash your creativity anywhere with SEQTRAK, the ultimate music creation station. Lightning-fast workflow allows you to capture ideas quickly, then create original music using its two versatile sound engines. When you’re ready, connect with fans using its powerful performance features and streamlined connectivity. SEQTRAK has everything you need. And more.
Features
- Capture ideas with a clear 3-part user interface and realtime, hands-on controls
- All-in-one system: drums, synths, sound design, sequencing – all included
- Advanced sequencer allows intuitive composition, quick arrangement and dynamic playback of musical tracks
- Create anywhere: compact, lightweight design plus built-in speaker, microphone and rechargeable battery
- Capture the world around you with Seqtrak’s onboard sampler
- AWM2 (Advanced Wave Memory 2) provides 128-note polyphony for authentic, realistic sounds
- Four-operator FM engine produces stunning synth pads, leads, FM electric pianos and more
- Comprehensive effects like reverb, delay, distortion and more provide a polished sound
- Performance features let you combine tracks and patterns, remix beats and mute/unmute tracks in real time
- The Seqtrak app visualizer mode transforms your music into a captivating visual experience
Specs
| SEQTRAK | ||
|---|---|---|
| Tone generator | ||
| Tone Generator | AWM2, FM: 4 operators | |
| Maximum Polyphony | AWM2: 128, FM: 8 | |
| Wave | Preset: 800 MB (when converted to 16-bit linear format), User: 500 MB | |
| Effects | Reverb × 12 types, Delay × 9 types, Master Effect × 85 types, Single Effect × 85 types, Master EQ 5 bands, LP-HP filters for each track | |
| Tracks | ||
| Track Types | DRUM, SYNTH, DX, SAMPLER | |
| Number of Tracks | 11 | |
| Sounds | ||
| Number of Sounds | Preset Sound: 2032 Preset Sampler Sound: 392 *Can be added from the SEQTRAK app | |
| Project | ||
| Number of Projects | 8 *Can be saved to the SEQTRAK app | |
| Connectivity | ||
| Connectors | USB | USB Type-C (power, MIDI to host, MIDI to device, audio) |
| Headphones | [PHONES] (stereo mini jack) | |
| A/D INPUT | [AUDIO IN] (stereo mini jack) | |
| MIDI | [MIDI] IN/OUT *Only included cable can be used. | |
| Functions | ||
| USB audio interface | [Sampling Frequency 44.1 kHz (quantization bit depth: 24-bit)] Input: 2 channels (stereo 1 channel), Output: 2 channels (stereo 1 channel) | |
| Bluetooth | MIDI transmission/reception (wireless capability varies by country) | |
| Wi-Fi | Data transmission/reception with dedicated app (wireless capability varies by country) The highest SAR value: 1.11 W/kg | |
| Sound System | ||
| Speakers | 2.3 cm, 1 W | |
| Microphone | Internal MEMS microphone | |
| Power Supply | ||
| Power Source | Rechargeable lithium-ion battery (2,100 mAh, 7.6 Wh) USB Power Delivery (PD) (Output voltage: 4.8 V to 5.2 V, Output current: 1.5 A or greater) | |
| Power Consumption | 6 W | |
| Battery life for continuous use | 3-4 hours | |
| Battery charge time | 3-5 hours | |
| Size/Weight | ||
| Dimensions | Width | 343 mm (13-1/2) |
| Height | 38 mm (1-1/2) | |
| Depth | 97 mm (3-13/16) | |
| Weight | Weight | 0.5 kg (1 lb 2 oz) |
| Packing Box | Width | 420 mm (16-9/16) |
| Height | 90 mm (3-9/16) | |
| Depth | 165 mm (6-1/2) | |
| Other | ||
| Included accessories | USB-C to USB-C cable, dedicated MIDI Converter Cable, Quick Operation Guide, Safety Guide | |
| Dedicated Software | SEQTRAK app | |
| Sequencer Block | Maximum Steps | 128 |
